Faucet and Watch PVD Coating Machine Titanium Nitride Coating Equipment

Faucet and Watch PVD Coating Machine Titanium Nitride Coating Equipment

Overview Product Description Advantage :High deposition rate ,High ionization rate ,easy operation ,High productivity an
Overview
Basic Info.
Model NO. TG1820
Condition New
Operation PLC Touch Screen
Structure Vertical or Horizontal
Paint Color Gold, Rose Gold, Blue, Gray, Black
Working Way Pumping to Coat
Core Selling Point Long Service Life
Process Environmental
Technology Multi Arc + Sputtering
Kinds of Coating Tin, Ticn
Control System Auto &Manual
Machine Size Custom Made
Weight 12 Tons
Install Location Customer Location
Chamber Material Stainless Steel 304
Application Decorative Coating
Transport Package Wrapping Film
Specification 1600*2000
Trademark Foxin
Origin China
HS Code 8543300090
Production Capacity 200 Units/Year
Product Description

Product Description

Advantage :High deposition rate ,High ionization rate ,easy operation ,High productivity and Low costApplication :Sanitary Supplies ,Door Lock ,Auto&Motorcycle partsColor: Ti-Gold , Rose Gold ,Black Gold , Coffee , Champagne Gold ,Japanese Gold , Multicolor ,etc.Film Feature :Wear resistance ,Corrosion resistance,High temperature resistance ,Excellent adhesion, Fast colorNote:Specially tailored according to customers' products and process requirements .
We can custom made machine size and configuration according to customer's request

FOXIN-TG Series Parameters
ModelTG-1010TG-1012TG-1215TG-1620TG-1820TG-2020
Chamber size(mm)D1000xH1100D1000xH1200D1200xH1500D1600xH2000D1800xH2000D2000xH2000
Pumping systemRough Pump + Roots Pump + Diffusion Pump(Turbo Pump) + Hold Pump
Measurement1 set pirani, 1 set cold cathode, 1 set diaphragm gauge
Arc Source6812182022
Arc Power Supply 200A
Bias Power Supply30KW40KW
GasAr, N2,C2H2,O2
Cooling Water cooling circulation, equip with industrial cooling tower or industrial water chiller(refrigerating machine) or cryogenic system.(customers provide)
Vacuum IndexExtract time (no load cold state): from atmosphere to 9.9×10-3Pa≤10min
Ultimate VacuumSuperior to 5.0x10-4Pa
Pressure Rising RateNew machine cold state air leaking rate≤0.5Pa/h
Running Power(kW)According to specific configuration
Output FrequencyCustom made
Occupation Space(m2)81012121212
Accessory EquipmentOven, Water Tower, Water Pump, Air Compressor, Jig Rack, Water Tank or Pool
RemarkAll configuration can be custom made

Detailed Photos

Faucet and Watch PVD Coating Machine Titanium Nitride Coating Equipment

Our Advantages

Double layer Vacuum Chamber
Foxin use double layer of stainless steel 304 to manufacture the vacuum chamber , with advanced welding technology and ensure the air tightness of the chamber . better vacuum pressure protection capability ,higher ultimate vacuum , More durable service life.and built in high power heater and ensure the temperature inside the chamber .Excellent vacuum pumping system
Foxin choose the famous Chinese brand pump for the vacuum pumping system . its Vacuum is fast and steady .to obtain high efficiency coating cycle time , greatly reduces the vibration frequency and energy consumption of the equipment Foxin offer the import brand pump service if the customer required.Foxin's 10th Arc Source and the Parts
Equipped with Foxin's 10th generation high-performance arc power supply and cathode arc source device , it means more uniform coating film , leading reliable performance of continuous coatingFoxin keep the technology R&D , so the technology are progressing . Control System and Famous Electrical Production
Foxin use the international cutting-edge brand s of the electrical production , such as Siemens , Mitsubishi . Especially the PLC .Foxin use the touch screen , easy to control the machine . Automatic system coating system , Foxin will base on the customer's products to set the program . the machine can be finish from pumping to coating automatically.

Faucet and Watch PVD Coating Machine Titanium Nitride Coating Equipment

Company Profile

Faucet and Watch PVD Coating Machine Titanium Nitride Coating Equipment

FAQ

Q1. How about the quality control about your products?
We have the ISO9001 QMS , CE certification.
All machine will past the internal quality test and field testing.
Q2. Does your company provide after-sale service ?
Yes. We have the field engineer to set-up and debug the machine .
After the machine is fully running . we have one year of quality warranty and full-life maintenance service .
Q3. Can you provide technical support about my work-flow?
Yes . The Foxin have more than 20 years of experience in Vacuum coating territory.
We also have an independent R&D department ,which will solve your production issue.
Q4. Do you provide the second-hand machine ?
No. All machine in Foxin are new .
We don't manufacture the second-hand machine .
Q5. Does your company supply accessories for our spare parts after we bought your products ?
Yes . We can supply you all the accessories especially for some consumable material .
